High Speed Perfume BOPP Wrapping Machine WBG QD480
Wanbon Boway Machinery Co., LTD is specialized at manufacturing packaging machinery and associated equipments. The key technical engineers possess 20 years experience in the packaging machinery.
Email: [email protected]
Product detail
High Speed Perfume BOPP Wrapping Machine WBG QD480
This bopp/pvc overwrapping machine is customized for packing perfume boxes, 12 sizes in total.
We export it to Algeria. and customers no need the tear tape.
(We have hidden the customer’s product logo)
The BOPP Wrapping Machine WBG QD480 main technical parameters:
| Packaging size | L(80-400)* W(70-230)* H(20-120)(mm) |
| Packing speed (bags/min) | （25-45） |
| Packaging Materials | BOPP or PVC |
| BOPP or PVC Inner hole diameter/thickness (mm) | Φ75/0.021-0.028mm |
| Air consumption (L/min) | (20-30)L/Min |
| Total power (kw) | 5.5 |
| Noise dB(A) | <65 |
| Dimensions (mm) | （standard）2594mm*1230mm*1997mm 3100mm*1500mm*1900mm |
| Overall weight (kg) | 1000 |
| Heat sealing temperature (℃) | 100-140 |
The host is controlled by a servo motor, ensuring stable operation andlow Equipped with a safety clutch device,
it automatically alarms and shuts down after squeezing, and automatically runs after resetting.
All electrical components are placed in an independent 304 stainlesssteel distribution cabinet, installed according to CE standards,
with weak and strong currents separated to ensure safe operation and more convenient.
