Wanbon Boway Machinery Co., LTD is specialized at manufacturing packaging machinery and associated equipments. The key technical engineers possess 20 years experience in the packaging machinery.
Email: [email protected]
Medicine box,poker,tea box,perfume box,tobacco packing.
*The flexibility to overwrap many product sizes on any one machine
*Tight wrap in either, polypropylene, cellophane, paper, clear and printed films
*Carton protection – prevention from carton surface damage
*Security – peace of mind the product has not been tampered with
*Seal area flexibility – allows the longitudinal seal to be positioned either on trailing edge or on the base of the carton, depending on carton design and marketing needs
*Geometrically exact end folds – giving that sleek finished look
*Easy open tear tape facility
The WBG type automatic transparent film wrapping machine is carefully designed and manufactured by our company based on the design concepts of Italy and Germany, using advanced three-dimensional computer-aided design software and mechanism motion analysis software, according to the characteristics of domestic packaging materials. This machine is a fully automatic packaging machine, using advanced PLC and servo motor control technology, which can be used independently or online.
It can achieve automatic progress of large size cases, including loading, stacking, hot sealing, reorganizing , counting，ect。 It’s your best choice to improve quality and efficiency of packaging, cut down cost and lift packaging grade.
|Packing Dimension L×W×H (mm)||（80-300）×（70-200）×（30-135）||（80-350）×（70-200）×（30-150）|
|Packing speed (packs/min)||（20-40）||（20-40）|
|Packing material||BOPP or PVC||BOPP or PVC|
|Inner hole diameter (mm)||Φ75/0.021-0.028||Φ75/0.021-0.028|
|Air consumption (L/min)||（20-30）||（20-30）|
|Total power (kw)||2. 25||2.25|
|Integrated noise dB(A)||<65||<65d|
|Total weight (kg)||1000||1000|
|Hot sealing temperature (℃)||100-140||100-140|
